Wind Turbine Generator
Product Features:1.Casting aluminum alloy body, compact, little vibration2.Excellent output,900w at 8m/s3.Easy installation, tube or flange connection optional4.Reinforced glass fiber blades,matched w
- Model：
Product Features:
1.Casting aluminum alloy body, compact, little vibration
2.Excellent output,900w at 8m/s
3.Easy installation, tube or flange connection optional
4.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization and annual output.
5.Tail adopts mechanical yaw technique, making it survive storm and run safely
6.Patented permanent magnet ac generator with special stator,effectively reduce torque, well match the wind wheel and generator,
and ensure the performance of whole system.
7.Controller,inverter can be matched according to customers’ specific needs
Package list:
1. one set wind turbine .
2.one set bolts and nuts.
3.one piece flange.
4. one piece charge controller.
Rated power | 5KW | 10KW | 15KW | 20KW | 30KW | 40KW | 50KW |
Maximum power | 6KW | 12KW | 17KW | 22KW | 32KW | 42KW | 52KW |
Rated voltage | 120V/220V/240V/380V/480V | ||||||
Start the wind speed | 2m/s | ||||||
Operating wind speed | 3.5m/s-13m/s | ||||||
Safe wind speed | 45m/s | ||||||
Number of blades | 3 | ||||||
Blade material | Reinforced FRP | ||||||
Insulation/protection rating | F / IP54 | ||||||
Magnetic steel material | NdFeB | ||||||
Generator type | Three-phase AC permanent magnet synchronous generator | ||||||
Control mode | Electromagnetic unloading/Mechanical spindle brakes | ||||||
Wind direction adjustment | Automatically adjusts the windward angle | ||||||
